Tinos V
Vertical designer radiators

Tinos V

The vertical design radiator Tinos creates a striking aura of aesthetic appeal with its straight lines. Tinos is an elegant addition to all interiors, traditional or modern.

The minimalistic design of Tinos stands out in every room, whether the living room, bedroom, kitchen or bathroom. As a result, you can enjoy the unique design and the pleasant heat from these beautiful radiators anywhere in the home. White RAL 9016. 70 special colours optionally available

Properties
Max operating temperature °C 110
Standard EN442; EN10130
Connection dimension 6 x G 1/2
Pressure rating PN10
Material Cold rolled steel
Standard colour White RAL 9016
Types 11; 21
Heights [mm] 1800; 1950; 2100
Widths [mm] 325; 475; 625; 775

ETIM MO Vertical mid-connection

ETIM MO Vertical connection

ETIM 18 Vertical connection

ETIM 18 Vertical connection

ETIM 45 Vertical connection

ETIM 45 Vertical connection.svg

ETIM MB Vertical Connection, in-left, out-right

ETIM MB Vertical connection.svg

Brackets, 3 dummy plugs and bleed screw.

Purmo radiators are warranted for a period of 10 years* from date of purchase against all manufacturing defects when they are used in normal conditions and for a heating system with hot water. The warranty does not apply to defects caused by installation or handling errors, misuse or factors external to the radiators, such as water quality or oxygen-permeable pipes.
Underfloor heating products and piping systems elements are warranted for a period of 10 years**.
* 6 years for galvanized radiators and 2 years for all electronic and electric components and spare parts sold separately (side covers, top grilles, plastic clips, plugs, air vents, fixing parts)
** 30 years for PexPenta pipes

10 year warranty

CE certificate

Files
DocumentCategory
Mounting instruction 2024 Tinos V Paros V Installation manual
Technical-Guide-Verticals 2024 Catalog
Data Sheet Technical data sheet
Tinos V Technical Datasheet 2024 Technical data sheet
Installation
