Aquilo FMS
Aquilo FMS trench convectors are specially designed for in-floor installation. The heating element is a copper-aluminum heat exchanger, painted black and mounted inside a double-side galvanized steel duct which is also painted black on the inside. On the top the convector is protected by a range of decorative grilles made of a choice of different materials. The grille is ordered separately. Grille material: wood (oak, beech) or duralumin in a choice of colours: natural, light brown, dark brown or black, stainless steel. The heat exchanger is connected to the heating system by two G ½” internal thread pipes. Warranty: 10 years
| Properties | |
| Max operating temperature °C | 110 |
| Standard | EN 16430 |
| Connection dimension | 2 x G 1/2 |
| Pressure rating | PN10 |
| Material | Several materials |
| Standard colour | Black |
| Types | FMS |
| Heights [mm] | 90; 110; 140; 190 |
| Widths [mm] | 700; 800; 900; 1000; 1100; 1200; 1300; 1400; 1500; 1600; 1800; 1999; 2200; 2400; 2500; 2600; 2700; 2800; 2900; 3000; 3200; 3400; 3600 |
Purmo radiators are warranted for a period of 10 years* from date of purchase against all manufacturing defects when they are used in normal conditions and for a heating system with hot water. The warranty does not apply to defects caused by installation or handling errors, misuse or factors external to the radiators, such as water quality or oxygen-permeable pipes.
Underfloor heating products and piping systems elements are warranted for a period of 10 years**.
* 6 years for galvanized radiators and 2 years for all electronic and electric components and spare parts sold separately (side covers, top grilles, plastic clips, plugs, air vents, fixing parts)
** 30 years for PexPenta pipes
CE certificate
| Document | Category |
|---|---|
| Heat output calculation in xls for Aquilo | Heat Output |
| Aquilo - Connection of a new model | Installation manual |
| Data Sheet | Technical data sheet |
