Radiator valve Evofit FVRF
Manual Valves Cooling

Radiator valve Evofit FVRF

The FVRF/FVVF thermostatic radiator valve is used in heating and cooling installations. FVRF/FVVF is used as a separate valve. FVRF/FVVF can be fitted with a thermostat or an electrical actuator. The FVRF/FVVF thermostatic radiator valve is pre-settable for precise balancing. The pre-setting is concealed. FVRF/FVVF is adapted to modern installations and is suitable for heating systems. FVRF/FVVF is equipped with quick couplings, and fits copper and PEX.

Properties
Max operating temperature °C 90
Connection dimension M28x1,5
Pressure rating PN10
Material Brass

PSE.111
Temperature-controlled radiator valves.
Thermostatic radiator valve with concealed, pre-settable spindle behind the stuffing box.
The valve must be manufactured with quick couplings.

Made by: AB Markaryds Metallarmatur
Type: FVRF
DN: 12/12 and 15/15
Models: Straight
