Radiator valve Evofit FVRF
The FVRF/FVVF thermostatic radiator valve is used in heating and cooling installations. FVRF/FVVF is used as a separate valve. FVRF/FVVF can be fitted with a thermostat or an electrical actuator. The FVRF/FVVF thermostatic radiator valve is pre-settable for precise balancing. The pre-setting is concealed. FVRF/FVVF is adapted to modern installations and is suitable for heating systems. FVRF/FVVF is equipped with quick couplings, and fits copper and PEX.
Properties | |
Max operating temperature °C | 90 |
Connection dimension | M28x1,5 |
Pressure rating | PN10 |
Material | Brass |
PSE.111
Temperature-controlled radiator valves.
Thermostatic radiator valve with concealed, pre-settable spindle behind the stuffing box.
The valve must be manufactured with quick couplings.
Made by: AB Markaryds Metallarmatur
Type: FVRF
DN: 12/12 and 15/15
Models: Straight
