Faro V
The Faro V's design is emphasised by a high-profile front and rounded perforated side panels. Like other vertical furnishing elements, the design is not only intended to provide a sense of height, it is also a powerful heat source in spaces where wall surface is at a premium. Faro V is available in a variety of different colours, including stainless brushed steel. For increased function in the bathroom and kitchen, a stylistically pure towel hanger is available in stainless steel as an accessory. Standard colour White RAL 9016.
Properties | |
Max operating temperature °C | 110 |
Standard | EN442; EN10130 |
Connection dimension | 6 x G 1/2 |
Pressure rating | PN10 |
Material | Cold rolled steel |
Standard colour | White RAL 9016 |
Types | 20; 21; 22 |
Heights [mm] | 1500; 1800; 1950; 2100 |
Widths [mm] | 300; 450; 600; 750 |
ETIM MO Vertical mid-connection
ETIM 18 Vertical connection
ETIM 45 Vertical connection
ETIM MB Vertical Connection, in-left, out-right
Purmo radiators are warranted for a period of 10 years* from date of purchase against all manufacturing defects when they are used in normal conditions and for a heating system with hot water. The warranty does not apply to defects caused by installation or handling errors, misuse or factors external to the radiators, such as water quality or oxygen-permeable pipes.
Underfloor heating products and piping systems elements are warranted for a period of 10 years**.
* 6 years for galvanized radiators and 2 years for all electronic and electric components and spare parts sold separately (side covers, top grilles, plastic clips, plugs, air vents, fixing parts)
** 30 years for PexPenta pipes
CE certificate
Document | Category |
---|---|
Mounting instruction Kos / Faro V and Vertical | Installation manual |
Technical-Guide-Verticals 2024 | Catalog |
Data Sheet | Technical data sheet |
Technical datasheet New Faro V | Technical data sheet |
